Wacker Neuson

WP1540A

WP1540A

5100018330
£1,199.76 GBP
£1,199.76 GBP
Sale On request
Shipping calculated at checkout.

5100018330

Compact single direction vibratory plate, compacts reliably on any compactor.
  • The control handle allows for effortless turning and manoeuvring
  • Sturdy design with minimum maintenance effort: The V-belt drive with all-round protection provides for a particularly long operating duration of the V-belt. The base plate is made from wear resistant nodular cast iron.
  • A sturdy tubular frame reliably protects the engine and water tank
  • Suspension points in the protective cage allow for safe transport. The guide handle that can be folded forward converts the unit into a compact unit in no time.

    •

  • Accessories, paving stone sliding mechanism, wheel set as well as water tank with sprinkler set available here in the shop
    • Exciter oil volume 0,15 l
    Exciter oil type 75W-90 API GL-4
    ENGINE Metric
    Inclined position max. 20,0 °
    Fuel management Carburettor
    Engine operating mode four-stroke
    Operating Engine speed 3.520 1/min
    Fuel consumption 0,80 L/hr
    Standard (Power max.) SAE J1349
    Standard (Effective power) ISO 3046 IFN
    Nominal Engine speed 3.600 1/min
    Tank capacity 3,60 l
    Electrode distance 0,7 - 0,8 mm
    Effective power 3,6 KW
    Oil filling max. 0,60 l
    Battery capacity (nom. value) 0 Ah
    Air cleaner dry air filter
    Power rating max. 3,6 KW
    Cooling air cooling
    Exhaust-gas limit EPA4/08
    Oil specification SAE 10W-30
    Starter battery Voltage 0 V
    Engine speed (Power max.) 3.600 1/min
    Starter type Recoil starter
    Oil filling min. 0,60 l
    Operating power 2,9 KW
    Engine type Gasoline engine
    Cylinder 1
    Engine Manufacturer Honda
    Standard (Operating power) ISO 3046 IFN
    Cylinder capacity 163 cm3
    Fuel Gasoline
    Spark plug(s) NGK BP-6 ES
    Oil volume incl. filter change 0,60 l
    MECHANICAL - OUTPUT DETAILS Metric
    Vibrations 5.880 1/min
    Gradeability 36,4 %
    Transmission FKK-KR
    Centrifugal force 15,000 kN
    Vibrations (Hz) 98 Hz
    Area capacity 749 m2/h
    Forward Running 29,00 m/min
    ELECTRICAL SYSTEM Metric
    Coding options -
    Electrode distance 0,7 - 0,8 mm
    Recommended Battery Typ -
    ENVIRONMENT DATA Metric
    Operating temperature range -15 - 40 °C
    Sound level LpA (Standard) EN 500-4
    Sound power LWA, guaranteed 108,0 dB(A)
    Storage temperature range -15 - 40 °C
    HAV summation (average value) 5,3 m/s2
    Uncertainty in measurement HAV 0,5 m/s2
    HAV summation (Standard) EN 500-4
    Sound level LpA 94,0 dB(A)
    Sound power LWA (Standard) EN 500-4, 2000/14/EG
    Sound power LWA, measured 107,0 dB(A)
    MECHANICAL DETAILS Metric
    Operating weight 86,0 kg
    Ground clearance 525 mm
    Height 961 mm
    Width 430 mm
    Length Drawbar in op. pos. 877 mm
    Custom Attributes Metric
    Model serie WP
