Dynapac
DFP9
DFP9
Regular price
£1,165.00 GBP
Regular price
Sale price
£1,165.00 GBP
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:
Built for easy use
The DFP series can be equipped with low vibration comfort handles with hand arm vibration (HAV) values that permit long working hours without documentation. Special centre mount handle is available in addition to the standard rear mount handle.
Standard
■ Foldable steering handle with vibration isolation
■ Highly wear resistant base plate
■ Automatic shutdown at low oil level
■ All around protection for V-belt
■ Protection frame for Engine
■ Recoil starter
■ Carrying handles
■ One point lift
■ Highly wear resistant base plate
■ Automatic shutdown at low oil level
■ All around protection for V-belt
■ Protection frame for Engine
■ Recoil starter
■ Carrying handles
■ One point lift
Optional
■ Water sprinkler system 7,0l (+10kg)
■ Comfort handle
■ Puncture proof transport wheels (+4kg)
■ Block paving mat
■ Service Kit
■ Comfort handle
■ Puncture proof transport wheels (+4kg)
■ Block paving mat
■ Service Kit
.
Technical Description
| Masses | |||
| Basic mass | 90 kg | ||
|---|---|---|---|
| Operating mass | 91 kg | ||
| Traction | |||
| Max. gradeability | 30 % | ||
| Max. working speed | 25 m/min | ||
| Compaction | |||
| Frequency | 90 Hz | ||
| Water tank volume | 7.0 l | ||
| Amplitude (front/rear) | 1.24 mm | ||
| Centrifugal force (front/rear) | 18 kN | ||
Engine / Drive |
|||
| Manufacturer | Honda | ||
| Model | GX 160 | ||
| Manufacturer/Model | Honda GX 160 | ||
| Emissions according to | Stage V / CARB Phase lll | ||
| Type | Air cooled gasoline | ||
| Number of cylinders | 1 | ||
| Fuel type | Gasoline | ||
| Fuel consumption /h, avg. | 1.1 l | ||
| Fuel tank capacity | 3.1 l | ||
| Power | 3.6 kW at 3600 rpm | ||
