Dynapac
CC800 Plus (80cm)
CC800 Plus (80cm)
Regular price
£18,495.00 GBP
Regular price
Sale price
£18,495.00 GBP
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:
| Technical Data | |
| Max. operating mass | 1665 kg |
|---|---|
| Operating mass (incl. ROPS) | 1575 kg |
| Module mass (front/rear) | 740 kg/ 835 kg |
| Traction | |
| Speed range | 0 - 9 km/h |
| Vertical oscillation | ±13° |
| Max. theoretical gradeability | % |
| Compaction | |
| Centrifugal force | 17 kN |
| Nominal amplitude | 0.4 mm |
| Static linear load, rear | 10.4 kg/cm |
| Static linear load (front/rear) | 9.3/ 10.4 kg/cm |
| Vibration frequency | 70 Hz |
| Water tank | 190 l |
| Engine / Drive | |
| Manufacturer/Model | Kubota D1105-E4B T4f/V |
| Type | Water cooled diesel |
| Rated power, SAE J1995 | 18 kW (24 hp ) @ 2800 rpm |
| Fuel tank capacity | 23 l |
| Alternative Engine | |
| Manufacturer/Model | |
| Hydraulic system | |
| Driving | Axial piston pump with variable displacement and servo. 2 radial piston motors with constant displacement. |
| Vibration | Gear pump/motors with constant displacement. |
| Steering | Gear pump with constant displacem. |
| Service brake | Hydrostatic in forward and reverse lever. |
| Parking/ Emergency brake |
Failsafe brake in both drums. |
