Dynapac
CC1200IV (120cm)
CC1200IV (120cm)
Regular price
£22,995.00 GBP
Regular price
Sale price
£22,995.00 GBP
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:
| Technical Data | |
| Max. operating mass | 3400 kg |
|---|---|
| Operating mass (incl. ROPS) | 2600 kg |
| Module mass (front/rear) | 1230 kg/ 1370 kg |
| Traction | |
| Speed range | 0-10 km/h |
| Vertical oscillation | ±10° |
| Max. theoretical gradeability | 42 % |
| Compaction | |
| Centrifugal force | 34/29 kN |
| Nominal amplitude | 0.5 mm |
| Static linear load (front/rear) | 10.3/11.4 kg/cm |
| Vibration frequency | 66/61 Hz |
| Water tank volume | 205 l |
| Engine / Drive | |
| Manufacturer/Model | Kubota D1703-M (IIIA) |
| Type | Water cooled diesel engine |
| Rated power, SAE J1995 | 26 kW (35 hp) @ 2800 rpm |
| Fuel tank capacity | 45 l |
| Alternative Engine | |
| Manufacturer/Model | Kubota D1703-DI (T4/V) |
| Type | Water cooled diesel engine |
| Rated power, SAE J1995 | 18.5 kW (25 hp) @ 2200 rpm |
| Alternative Engine | |
| Manufacturer/Model | Kubota D1803-CR (T4/V) |
| Type | Water cooled diesel engine |
| Rated power, SAE J1995 | 28 kW (37.5 hp ) @ 2700 rpm |
| Hydraulic system | |
| Driving | Axial piston pump with variable displacement and servo. 2 radial piston motors with constant displacement. |
| Vibration | Gear pump/motors with constant displacement. |
| Steering | Gear pump with constant displacement. |
| Service brake | Hydrostatic in forward and reverse lever. |
| Parking/ Emergency brake |
Failsafe multidisc brake in both drums. |
